Food Grade 3 Way Clamp Pneumatic Ball Valve Wholesale,Supply Various Food Grade 3 Way Clamp Pneumatic Ball Valve of High Quality

Unit Price:	50~75 USD
Min. Order:	1 Piece/Pieces

Model No.: Fosic-3 Way Ball Valve

warranty period: 3 Years

Types of: Ball Valves, Kitchen Gas Shut-Off Valves, Gas Appliance Isolation Shut-Off Valves, Emergency Shut-Off Valves, Truck Shut-Off Valves, Vacuum Relief Valves, Air &Amp; Vacuum Release Valves

Certification: Csa, Pcoc, Reach, Epa, Gs

Support customization: Odm, Oem, Obm

place of origin: China

application: General, Commercial Kitchen, Home Kitchen

Medium temperature: Medium Temperature, Normal Temperature

power: Pneumatic

Flow medium: Gas, Water

structure: Ball, Check, Regulating, Shutoff

Pneumatic Actuator: Double Acting ,Single Action

Driving Air Source: 5-7bar Compressed Air

Nominal Diameter: DN15-250mm

Nominal Pressure: 1.6-6.4Mpa

Applicable Temperature: PTEF:-30℃-180℃ PPL:-30-250℃

Connection Mode: Clamp,Flange,Weld

Structure: 3 Way T Shaped , 3 Way L Shaped

Material: WCB, 304, 316, 316L

Media: Gas, Liquid

Packaging: Paper Box

Productivity: 10000 Piece/Pieces Per Month

Brand: Fosic

Transportation: Ocean,Land,Air,Express

Place of Origin: Wenzhou, Zhejiang, China

Supply Ability: 10000 Piece/Pieces Per Month

Port: Ningbo ,Shanghai,Guangdong

Ball valve with pneumatic actuator is a kind of valve, can be divided into L type and T type. L-type three-way ball valve is used to switch the flow direction of the medium, so that the two vertical channels can be connected. The sanitary stainless steel ball valve commonly used in industries such as food and beverage, pharmaceutical, and biotechnology, where maintaining a high level of cleanliness and preventing contamination is crucial.

Furthermore, the clamped ball valve is easy to clean and maintain, thanks to its simple design. It can be disassembled and cleaned thoroughly, ensuring that no residue or buildup is left behind.

Double acting pneumatic three-way ball valve:

1. Pneumatic three-way ball valve open: 2-port intake, 4-port exhaust, push the two pistons to move separately to both sides, and the output shaft rotates counterclockwise.

2. Pneumatic three-way ball valve close :4 inlet air, 2 exhaust, push the two pistons to the center, the output shaft rotates clockwise.

Single-acting pneumatic three-way ball valve:

1. Pneumatic three-way ball valve open :2 inlet air, 4 outlet exhaust, push the two pistons to move to both sides separately, while compressing the spring, the output shaft rotates counterclockwise.

2. Pneumatic three-way ball valve close: when the gas is lost or the power is lost, the spring pushes the two pistons to move to the center, and the output shaft rotates clockwise.

Workflow Schematics:

T Shaped Or L Shaped Flow Diagram
